Small Size. Big Power.

Smart PDUs for compact AV installations

GUDE’s compact power distribution units (PDUs) enable fast and cost-effective managed services, even in the most confined spaces. They are real problem solvers when it comes to efficient energy management.

The award-winnig PDUs were developed to fit into any AV installation thanks to its compact casing: Behind displays of UC rooms, under tabeltops in huddle spaces or in small media furniture and lecterns.

Request your free demo unit

Expert Power Control 1141 is a 4-way switched power distribution unit with integrated safety functions as well as power measurement and environmental monitoring. This IP-based power solution enables operators of AV installations to gain full control over their infrastructure: Up to four AV devices connected to the power sockets can be supplied with power and individually switched and controlled.

The smaller brother is Expert Power Control 1121: The networked socket outlet has the same range of functions and two switchable ports in an even smaller and thinner housing.

Benefits for AV Experts

Less downtime: Detailed power and sensor monitoring keep an eye on your AV setup in real time. Integrated surge protection and quality high-inrush relays provide additional safety.
Easy integration: Free plug-n-play drivers seamlessly integrate the PDUs with solutions from AMX, Biamp, Control4, Crestron, Extron, Savant and Q-SYS.
More sustainability: The network-compatible power distributors enable AV devices to be switched off and on collectively. The battle is declared against power guzzlers that would otherwise cause massive electricity costs in 24/7 operation, even in standby.
Faster managed service: Remote reboots or automatic power cycling on hangs of media players, servers and streaming devices.

Get in contact

Greater safety for your AV installation

GUDE’s intelligent PDUs offer a range of robust safety features to protect business-critical AV environments:

Surge protection: Integrated type 3 surge protection devices (SPDs) safeguard AV systems from harmful voltage spikes and ensure optimal performance and longevity.
Long-life high-current relays: Prevent relay contacts from welding during inrush current peaks
Encrypted communication: Security through SSL (TLS 1.1, 1.2, 1.3) and SSH
Zero Voltage Switching (ZVS) avoids high switching currents by switching at the zero crossing of the AC voltage

Free plug-n-play drivers from our trusted AV technology partners

Faster service, higher security & reduced costs

Discover how these compact IP power distribution units support you in getting the most out of your next AV project: Effectively expand your AV installation with customised power management and reliable environmental monitoring.

Small 2-fold switched and metered PDU

Part number: 1121
Input current: 10 A, 100-240 V
Number power ports: 2
Control interface: LAN
Environment monitoring: 1 sensor connector
Installation: Media furniture, walls, under table tops
Power port type: IEC C13

Small 4-fold switched and metered PDU

Part number: 1141
Input current: 10 A, 100-240 V
Number power ports: 4
Control interface: LAN or RS232
Environment monitoring: 1 sensor connector
Installation: Media furniture, walls, under table tops
Power port type: IEC C13

About GUDE

GUDE has been a manufacturer of innovative audiovisual and IT equipment for over 35 years. The family-owned company’s quality products optimize and expand infrastructures such as those found in network, server and media cabinets. The Cologne-based company’s product portfolio includes power distribution units (PDUs), LAN sensors and time servers. The solutions are designed and manufactured in Germany to meet customers’ quality requirements for AV and IT infrastructure performance. The company’s mission: to delight customers and save time integrating products for AV and IT professionals.
